Dynamic Temperature Control System
Integrated refrigeration, electric heating, circulation and intelligent HMI/PLC control for rapid temperature rise and fall in reactor and process applications.
product details
Product overview
Dynamic temperature control systems combine refrigeration, electric heating, circulation and control into one unit so jacketed reactors and process equipment can move quickly between heating and cooling stages.
Where this route fits
- Jacketed reactor temperature control
- Pilot process heating and cooling
- Material testing with programmed temperature profiles
- Chemical process utilities with circulation loops
What to provide before quotation
- Target operating temperature range and maximum temperature
- Reactor volume or process volume
- Heat transfer medium and circulation path
- Required heating / cooling rate, flow and lift
- Power supply, installation location and hazardous-area requirement
Specification summary
| Temperature range | -80°C to 200°C; 300°C optional on selected systems |
|---|---|
| Control accuracy | ±0.5°C on GDX dynamic systems |
| Control mode | Material temperature and outlet temperature switching |
| Operation panel | 7-inch MCGS HD screen or Siemens screen optional |
| Communication | Modbus RTU RS485; RS232/Ethernet optional |
| Applications | Jacketed reactors, pilot plants, material testing, process temperature profiles |
Configuration options typically discussed before order release
- 7-inch MCGS HMI or Siemens PLC / Siemens screen control route
- Material temperature or outlet temperature control strategy
- RS485 Modbus RTU, RS232 or Ethernet communication package
- Air-cooled or water-cooled condenser structure depending on duty
- Explosion-proof and project-specific utility configuration where required
Typical delivery scope discussion
- Main temperature-control unit with refrigeration, heating and circulation system
- Control cabinet, operating screen and standard protection package
- Matched documentation path through selection guide and parameter checklist pages
- Accessory and interface scope confirmed according to the project quotation
Installation and site-preparation notes
- Confirm voltage, frequency and cooling-water or standalone condenser requirements before order release
- Confirm circulation route, interface size and installation footprint with the reactor or process skid
- Confirm hazardous-area classification, ambient conditions and commissioning-side control expectations
Related resources
Frequently asked questions
What information is needed for model selection?
Target temperature range, reactor volume, heat transfer medium, voltage, flow and lift expectations, cooling type, and installation environment.
Can explosion-proof configurations be discussed?
Yes. Share the hazardous-area requirement and application details so UnionClay can confirm suitable configuration options.
